3 Outlet Bottom-Feed D-Box

The 3-Outlet (Bottom Feed) Distribution Box is a concrete box designed for distribution of effluent wastewater to a home's leach field.  The 3-outlet Bottom Feed is used for smaller sized leach fields with up to (3) 4" outlet pipes.  It has (2) inlets; side inlet for gravity feed and a bottom inlet for pressure feed.

Specifications

• Category:D-Boxes
• Use:Commercial, Residential
• Class:Pedestrian
• Type:Concrete
• Weight:Base: 145# / Cover: 55#
• Interior Dimensions:12"L x 12"W x 8.75"H
• Exterior Dimensions:20.25"L x 20.25"W x 13.25"H
• Invert Out:5.5"
• Invert In:3.5"
